Metallic Blue Roll Stock
Roll Width: 7.08"
Roll Length: 3,937'
Thickness: 1.77 Mil
Color: Gold
Material: Multi Layer Metalized Poly
Core Size: 3"

Metallic Green Roll Stock
Roll Width: 7.08"
Roll Length: 3,937'
Thickness: 1.77 Mil
Color: Gold
Material: Multi Layer Metalized Poly
Core Size: 3"

Includes:
- Product Detection (SICK GTB6)
- Sensor Mount
- PLC Sensor Integration and Programming

Violet Multilayer Roll Stock
Roll Width: 5.50"
Roll Length: 3608'
Color: Violet
Material: Multi Layer Poly
Core Size: 3"

Diameter: 36"

K 0~600°C
Solid State Relay
100-240VAC,50/60Hz

Red: 12~30VDC
Black: O V
White: H Out
Green: L Out

Sensing Type: Through Beam
Width: 1.73" [44mm]
Thickness: 0.23" [6mm]
Height: 0.74" [19mm]

Input: VAC 220 A 2.6 INS. B
Output: r/min3000 N.m1.27 kW0.4

Top Cavity Size: 0.744" x 1.956"
Bottom Cavity Size: 2.224" x 0.905"
Number of Cavities: 26 (2 rows of 13)

Brown: 12-24V DC, Class 2
Blue: 0V
Black: OUT1(30V 100mA)

Machine Type: Label Applicator Machine
Full Touch Screen Operation with PLC Controller
Automatic Fault Alarm
Automatic Label Detection and Position Adjustment
High Precision Small Inertia Step Motors Provide Precise Label Positioning
Low Wear Emery Rollers
Quick Label Changeovers
Can be Integrated with New or Existing Production Lines or be Linked to Feeding Equipment
Labeling Speed: 30-150 Labels Per Minute
Applicable Label Size: Min W 0.79” x L 0.79” Max W 2.36” x L 11.81”
Labeling Accuracy: ± 1mm (Does not include product and label errors)
Voltage: 220V, 50/60Hz
Machine Size: 13.82” x 8.03” x 16.93”
Options: Transparent Label Sensor

Gas Regulator
Gas Control Valve
Gas Flush Tubing Assembly
Gas Flush Support Rail

Power: 24V 0.3A Class 2
In: 24V Class 2
Out: 0.2A 24V Class 2

Power: 12-24VDC 100mA
Sensor Type: NPN NO OR NC
BN: V+
BK: OUT
BU: V-

Power: DC10-30V
Sensor Type: NPN

50-30VDC
NPN
300 mA
5mm
